Troubleshooting
4-5
PowerFlex 40 Adjustable Frequency AC Drive FRN 1.xx - 6.xx User Manual
Publication 22B-UM001H-EN-E
Motor does not Start.
F100 Parameter
Checksum
➁
The checksum read from the
board does not match the
checksum calculated.
[Reset To Defalts] to
option 1 “Reset Defaults”.
F122 I/O Board Fail
➁
Failure has been detected in the
drive control and I/O section.
1. Cycle power.
2. Replace drive if fault cannot be
cleared.
(1)
See
for a description of fault types.
No.
Fault
Ty
p
e
(1
)
Description
Action
Common Symptoms and Corrective Actions
Cause(s)
Indication
Corrective Action
No output voltage to the motor.
None
Check the power circuit.
•
Check the supply voltage.
•
Check all fuses and disconnects.
Check the motor.
•
Verify that the motor is
connected properly.
Check the control input signals.
•
Verify that a Start signal is
present. If 2-Wire control is used,
verify that either the Run
Forward or Run Reverse signal
is active, but not both.
•
Verify that I/O Terminal 01 is
active.
•
[Start Source]
matches your configuration.
•
[Reverse
Disable] is not prohibiting
movement.
Improper boost setting at initial
start-up.
None
Set
[Boost Select] to option 2
“35.0, VT”.
Drive is Faulted
Flashing red status light
Clear fault.
•
Press Stop
•
Cycle power
•
[Fault Clear] to option 1
“Clear Faults”.
•
-
[Digital Inx Sel] is set to option 7
“Clear Fault”.
