22
Display After Operation Key Explanation
5
ENTER
•
Press the Enter and the ｢Ramp
Level ｣-edit mode starts. ｢rL｣
appears blinking on the indicator.
6 •
Three seconds later, the previous
ramp level appears blinking on the
indicator, showing that you can
change values. The ramp level is set
at 500hPa in the example.
7
▼▲ ▼▲ ▼▲ ▼▲
•
Press ｢▲｣ or ｢▼｣ and change to
the ramp level you desired. To
increase values, keep on pressing
｢▲｣. Once values reached
｢660hPa｣ ,the maximum, it stops
increasing. To decrease values, keep
on pressing
｢▼｣. Once values
reached ｢66hPa｣, the minimum, it
stops decreasing.
•
The ramp level is set at 200hPa using
｢▼｣ in the example.
8
ENTER
•
Press ENTER and the changed set
point is restored. The edit mode
ends.
•
These new level and time alternately
appear blinking on the indicator.
•
｢EDIT｣ LED is off.
