18
Shifting to Other Operation
Display After Operation Key Explanation
1 •
The ramp control is running.
2
OPERATION
MENU
•
Press OPERATION MENU while the
operation runs, and the selecting
mode appears on the indicator,
showing a feasible controls
(depending on what operation is
running). The control modes are
scrolled by OPERATION MENU.
•
The ramp control is shifted to the
fixed value control or the free mode. It
is shifted to the fixed value control
mode in the example on the left.
Select the control mode you desired
and press ENTER to shift. The
present operations continues unless
ENTER, which is used to decide the
control mode,is pressed. Thus, the
lamp of the present operation mode
is on,at the same time,the next-mode
lamp blinks at this stage.
3
ENTER
•
Select the control mode you desired
and press ENTER. Then the control
is shifted.
•
The lamp of the mode which was
selected newly turned on, and the
privious-mode lamp is off.
