Accessible reveal panels, Components – USG Ceiling True Wood User Manual
Page 14
13
Components
aCCeSSiBle
reVeal PanelS
Panel options
Size
2' x 2'
2' x 4'
Edge Detail
AR
Perforations (see page 21)
W400
acoustical Performance
Perforated Lay-In panels come standard with a black, factory-applied Acoustibond
backer for enhanced sound performance. The Acoustibond backer is included on all
perforated panels unless otherwise specified. This backer is also available in white. For
even greater acoustical performance, fiberglass backing is available.
Perforation
open area
nrC
W100
10%
.60
W200
3%
.30
W300
20%
.70
W400
5%
.40
Suspension Systems
DX
DX tee
True Wood
concealed panel
Panel installation
