Frame-mounted backlit system, Installation — fineline, Grid – USG Pixels Wall Mounted User Manual
Page 30: Step 7, Step 8
28 P
ixels
™
Design and Installation Guide
Step 7
Tuck foam into space between grid
and trim to block light leaks. Be sure
to push foam all the way to the face
of the trim.
Step 8
Assure the system is square.
Frame-Mounted Backlit System
Installation — Fineline
®
Grid
Installation Detail
P
IXELS
wall mount
pre-mitered frame
S
HEETROCK
gypsum panel
wood backing
friction fit foam to
seal off light leaks
around perimeter
tees
P
IXELS
panel or
C
ELEBRATIONS
panel
