FPI FP90 Wood Fireplace 16
INST
ALLA
TION
installinG tHe
outside air Kit
Combustion air is fed to the firebox through a
connection on the rear lower left side of the unit.
A free flowing supply of air must be available to
this opening at all times. Combustion air may be
taken from inside the building if the local building
code allows, but performance may suffer. Also,
it must go through the 6" (152mm) duct to the
connection on the left hand side.
Air drawn from the interior of the building will
affect the performance of gas or oil furnaces,
and exhaust fans and fan driven appliances.
This may cause a negative pressure in the
house allowing smoke to back into the home.
Outside Air Inlet must be 6 ft. (152mm) below
the chimney termination point
Insulated Metal
6” Duct
Exterior
Wall
Outside
Metal
Vent
Side Connection
Unit
The preferred source of combustion air is from
outside the building. If possible, install the kit
on the wind loading side of the building not the
leeward or (negative pressure) side.
note: do not obtain combustion air from
attic, garage or other enclosed space.
1) Put the supplied insulated air duct to a nearby
exterior wall. Maximum length of duct is 20ft
(6.1m). Duct length should be kept to a
minimum and as straight as possible. note:
4 ft. only is supplied with unit. Termination
should be in an area with good air flow.
2) Ensure that your air source is not close to
automobile exhaust, gas meters or other
vents.
3) Cut a 7" (178mm) hole through the wall and
mount the outside air kit.
4) Attach the two ends of the duct (making
sure not to damage the insulating cover)
after installing the flange on the fireplace
side. Duct must be secured by screws or
clamp.
installation
taBle 1
required firestop, radiation shield, or attic insulation shield
Model 1st floor 2nd floor into attic
CF Sentinal Intermediate Joist Shield Attic Insulation Shield
Super Pro 2100+ Attic Insulation Shield Attic Insulation Shield
Super Vent 2100+ Attic Insulation Shield Attic Insulation Shield
Security S2100+ Radiation Shield Fire Stop Insulation Radiation Shield Attic Radiation Shield
Oliver Macleod Project HT6000+ Radiation Shield Fire Stop Insulated Attic Radiation Shield
Simpson DuraPlus HTC Fire Stop Radiation Shield Attic Insulation Shield
ICC Excel 2100 Radiation Shield Radiation Shield with Storm Collar
taBle 2
Minimum recommended flue Height in feet
(Measured from the top of the solid fuel appliance)
eleVation (ft)
aBoVe sea leVel
# of elBoWs
0 2 x 15 o 4 x 15 o 2 x 30 o 4 x 30 o 2 x 45 o 4 x 45 o
0ft - 1000ft
(0m - 305m)
12.00ft
(3.66m)
13.00ft
(3.96m)
14.00ft
(4.27m)
15.0ft
(4.57m)
18.00ft
(5.49m)
16.00ft
(4.88m)
20.0ft
(6.10m)
1000ft - 2000ft
(305m - 610m)
12.48ft
(3.80m)
13.52ft
(4.12m)
14.56ft
(4.44m)
15.6ft
(4.75m)
18.72ft
(5.71m)
16.64ft
(5.07m)
20.0ft
(6.10m)
2000ft - 3000ft
(610m - 914m)
12.96ft
(3.95m)
14.04ft
(4.28m)
15.12ft
(4.61m)
16.2ft
(4.94m)
19.44ft
(5.93m)
17.28ft
(5.27m)
21.6ft
(6.58m)
3000ft - 4000ft
(914m - 1219m)
13.44ft
(4.10m)
14.56ft
(4.44m)
15.68ft
(4.78m)
16.8ft
(5.12m)
20.16ft
(6.14m)
17.92ft
(5.46m)
22.4ft
(6.83m)
4000ft - 5000ft
(1219m - 1524m)
13.92ft
(4.24m)
15.08ft
(4.60m)
16.24ft
(4.95m)
17.4ft
(5.30m)
20.88ft
(6.36m)
18.56ft
(5.66m)
23.2ft
(7.07m)
5000ft - 6000ft
(1524m - 1829m)
14.40ft
(4.39m)
15.60ft
(4.75m)
16.80ft
(5.12m)
18.0ft
(5.49m)
21.60ft
(6.58m)
19.20ft
(5.85m)
24.0ft
(7.32m)
6000ft - 7000ft
(1829m - 2134m)
14.88ft
(4.54m)
16.12ft
(4.91m)
17.36ft
(5.29m)
18.6ft
(5.67m)
22.32ft
(6.80m)
19.84ft
(6.05m)
24.8ft
(7.56m)
7000ft - 8000ft
(2134m - 2438m)
15.36ft
(4.68m)
16.64ft
(5.07m)
17.92ft
(5.46m)
19.2ft
(5.85m)
23.04ft
(7.02m)
20.48ft
(6.24m)
25.6ft
(7.80m)
8000ft - 9000ft
(2438m - 2743m)
15.84ft
(4.83m)
17.16ft
(5.23m)
18.48ft
(5.63m)
19.8ft
(6.04m)
23.76ft
(7.24m)
21.12ft
(6.44m)
26.4ft
(8.05m)
9000ft - 10000ft
(2743m - 3048m)
16.32ft
(4.97m)
17.68ft
(5.39m)
19.04ft
(5.80m)
20.4ft
(6.22m)
24.48ft
(7.46m)
21.76ft
(6.63m)
27.2ft
(8.29m)
