SPYPOINT TINY-W3 - Manual (Page 7)

7
Components • Receiver
(BLACKBOX)
1
2
3
7
6
4
5
1 Antenna Allows wireless communication between the
BLACKBOX and the camera.
2 12V power jack The receiver can be powered from an ex-
ternal 12-volt DC input such as a 12V bat-
tery or a 12V adapter, each sold separately
(p.11).
3 Slot for installation
strap
Allows the user to install the receiver
using the installation strap included
(p.23).
4 Battery case Case for AA batteries (p.11).
5 SD card slot An SD card is required to record photos
(p.15).
6 Test light Allows the user to know the battery status
(p.11) and indicates the synchronization
period (p.24).
7 ON/OFF Allows the user to turn on/off the device.
