appendIx C: Modbus® speCIfICaTIons
Inputs TYPE VALID RANGE BASE OFFSET
input Calibration (fixed-point integer) sint16 ±300 .00 4x10496 169
normal logging Frequency (max 31 days) uint32 0 - 2678400 s . 4x10500
alarm logging Frequency (max 31 days) uint32 0 - 2678400 s . 4x10502
alarm low limits float ±80000 .00 4x10583
alarm high limits float ±80000 .00 4x10585
low table limit (4-20ma) float ±80000 .00 4x10587
high table limit (4-20ma) float ±80000 .00 4x10589
summary page Gauge low limit float ±80000 .00 4x10591
summary page Gauge high limit float ±80000 .00 4x10593
name string 0 - 32 characters 4x10595
recognition Time uint16 0 - 28800 s . 4x10627
alarm reset time (seconds) (max 8 hours) uint16 0 - 28800 s . 4x10629
input Type uint8 0x00 - 0xFF 4x10631
Custom Units of Measure string 0 - 16 characters 4x10632
Type of Units uint8 0x00 - 0xFF 4x10648
arbitrary ordering number for this i/o point uint8 0x00 - 0xFF 4x10649
Outputs
output set point
float 0 .0=off, 1 .0=on 4x10592
Minimum value float ±80000 .00 3x01536 42
Minimum value (fixed-point integer) sint32 ±80000 .00 3x01538
Maximum value float ±80000 .00 3x01540
Maximum value (fixed-point integer) sint32 ±80000 .00 3x01542
last alarm (timestamp) uint32 any value 3x01546
real value (floating-point) float ±80000 .00 3x01550
real value + units (string) string any non-null 3x01552
real value (fixed-point integer) sint32 ±80000 .00 3x01576
Enables/Disables the entire i/o point . bit TrUE or FalsE 0x01536 32
Enables/Disables alarming bit TrUE or FalsE 0x01537
Enables/Disables alarm on return-to-normal bit TrUE or FalsE 0x01540
reset the Minimum bit TrUE 0x01552
reset the Maximum bit TrUE 0x01553
alarm Condition uint8 0x00 - 0xFF 1x00256 42
realtime state, ignoring recognition time . uint8 0x00 - 0xFF 1x00270
USER PROFILES TYPE VALID RANGE BASE OFFSET
access level uint8 4x00768 86
Call escalation priority level uint8 0x00 - 0xFE 4x00769
