Orbital Minotaur I User Manual
Page 91
Minotaur I User’s Guide
Appendix A
SPACECRAFT PHYSICAL DIMENSIONS
STOWED
CONFIGURATION
Length/Height:
Diameter:
in cm
in cm
Other Pertinent Dimension(s):
Describe any appendages/antennas/etc which extend beyond the basic satellite
envelope:
ON-ORBIT
CONFIGURATION
Describe size and shape:
If available, provide dimensioned drawings for both stowed and on-orbit configurations.
Release 3.0
March 2014
A-5
