81 Using the Car Seat on the Stroller
Always secure your child with the restraint harness when using
the car seat with the stroller.
Avoid injuries to your child during stroller use:
• Always fully support the car seat by firmly grasping both carry
handles when docking and undocking from the stroller.
• Always make sure the car seat is securely locked into the
SmartHub of the stroller.
• Only rotate the car seat when the stroller is stationary and the
parking brakes are locked.
• Always make sure that the car seat is locked in front- or rear-
facing position before strolling. Side-facing positions are for
stationary use only.
PINCH HAZARD: Keep hands and fingers clear of moving parts,
the release levers, and the SmartHub.
⚠WARNING⚠
Death or Serious Injury Can Occur
Docking and rotating the car seat:
1. Make sure the stroller is unfolded,
and the SmartHub is clear of objects,
before docking the car seat.
2. Lock the parking brakes on the stroller.
3. Grasp the car seat firmly by both carry
handles (Photo A). Dock the bottom
of the car seat into the SmartHub until
you hear and feel a
CLICK (Photo B).
4. Rotate the car seat to a locking
position. CHECK the security of the
docking by pulling up on the car seat.
5. To rotate the car seat, grasp the carry
handle, pull the release lever and rotate
to the next locking position (Photo C).
Undocking and removing the car seat:
1. Lock the parking brakes on the stroller.
2. Grasp the car seat firmly by both carry
handles.
3. Squeeze either release lever upwards.
4. Lift the car seat out of the Stroller and
remove it carefully.
Refer to the instruction manual that accompanied your Orbit Baby Stroller
for complete instructions on using and maintaining your stroller.
C
B
A
