Orbit Baby G3 Infant Car Seat and Base - Manual (Page 26)

Installing the Car Seat Base and Car Seat
Installing the Car Seat Base and Car Seat
51
51
50
50
51
51
Installing the Car Seat on the Car Seat Base: Overview
⚠WARNING⚠
Death or Serious Injury Can Occur
Never operate your vehicle unless the car seat is LOCKED into
the rear-facing position. Check both rotation indicators on the car
seat base. If either rotation indicator is red, re-secure the car seat to
properly lock into the car seat base.
When a release lever on the car seat is pulled, the car seat is not
secured properly to the car seat base. Only use the release levers
when rotating or removing the car seat. Do not allow children to
operate the release levers.
Once the car seat base is installed, the car seat can be docked and locked onto
the car seat base conveniently. The car seat MUST be locked in the car seat
base in the rear-facing position when the vehicle is in motion.
Docking the Car Seat on the
Car Seat Base
1. Installing the car seat on
the car seat base:
See Docking the Car Seat
on the Car Seat Base.
C
B
A
Securing the car seat to the car seat base
requires first lowering the car seat to snap
into the SmartHub, then rotating the car
seat to lock into the rear-facing position.
1. Make sure the top of the car seat base
and SmartHub are clear of objects
(Photo A) before docking the car seat.
2. Grasp the car seat firmly by both carry
handles (Photo B). Dock the bottom of
⚠WARNING⚠
Death or Serious Injury Can Occur
PINCH HAZARD:
• Ensure that your child’s fingers
and hands are clear of release
levers, soft carrier handle, and
other moving parts.
•
When installing the car seat,
make sure the hands of other
vehicle occupants are clear of
the SmartHub area.
