4 - OPTICON

---------------------------------------------------------------

[STEP 3 A]
CONNECT BY SCANNING

– CRADLE

• Scan the device address barcode on the bottom

of the cradle.

– OTHER DEVICE

• Scan the address barcode that you just created in

the on-line Opticon application (step 1).

---------------------------------------------------------------

[STEP 3 B]
DISCOVER

Set the reader in discoverable and connectable
mode:

• If an Opticon cradle is supplied: Place the reader

in the cradle. The reader is discoverable while it
is in the cradle.

• If no cradle is supplied: Scan the label to make

the reader discoverable for 3 minutes.
(SET + END label not required):

Set the PC / Other device to discover the reader:

• The name of the reader will be displayed as

Productname-xxxx. Example (OPL2724-3969)

CONNECT

Connect the PC / Other device to the reader:

• Follow the instructions of the device.
• The application might ask for a PIN-code. In this

case the 4 last reader name characters are
entered into the application.
(Example: reader name is OPL2724-3969,
required application PIN-code is 3969)

---------------------------------------------------------------

---------------------------------------------------------------

[STEP DISCONNECT]

(SET + END label not required):

---------------------------------------------------------------

[STEP RESET]

---------------------------------------------------------------

Make discoverable & connectable

_+-DSCO-+_

+-DSCO-+

Manually disconnect

_+-DISC-+_

+-DISC-+

SET

_ZZ_

ZZ

Reset

_SO_

SO

END

_ZZ_

ZZ
