4.0
LED INDICATORS
4.1
4Tx Switch Module
The 4Tx Switch Module has LED indicators to provide connection information.
4Tx Switch Module
LED Function
Color
Off State
ON State
Power "Pwr"
Yellow
No Power
On: Module has Power
Port 1 "100 Link"
Green
Not Linked at 100Mbps On: Port Linked at 100Mbps
Blinking: Data Activity
Port 1 "10 Link"
Green
Not Linked at 10Mbps
On: Port Linked at 10Mbps
Blinking: Data Activity
Port 2 "100 Link"
Green
Not Linked at 100Mbps On: Port Linked at 100Mbps
Blinking: Data Activity
Port 2 "10 Link"
Green
Not Linked at 10Mbps
On: Port Linked at 10Mbps
Blinking: Data Activity
Port 3 "100 Link"
Green
Not Linked at 100Mbps On: Port Linked at 100Mbps
Blinking: Data Activity
Port 3 "10 Link"
Green
Not Linked at 10Mbps
On: Port Linked at 10Mbps
Blinking: Data Activity
Port 4 "100 Link"
Green
Not Linked at 100Mbps On: Port Linked at 100Mbps
Blinking: Data Activity
Port 4 "10 Link"
Green
Not Linked at 10Mbps
On: Port Linked at 10Mbps
Blinking: Data Activity
4 Port Switch Module LED Indicators
Page 11
