SPECIFICATIONS:

Form: 040-12000-001E 1/13

Warning

The operating description in this Instruction Manual is

for use by qualified personnel only. To avoid electrical

shock, do not perform any servicing of this unit other

than that contained in the operating instructions, unless

you are qualified and certified to do so by Omnitron

Systems Technology, Inc.

Warranty

This product is warranted to the original purchaser

against defects in material and workmanship for a

period of TWO YEARS from the date of shipment. A

LIFETIME warranty may be obtained by the original

purchaser by REGISTERING this product with

Omnitron within 90 days from the date of shipment.

TO REGISTER, COMPLETE AND MAIL OR FAX

THE ENCLOSED REGISTRATION FORM TO THE

INDICATED ADDRESS. Or you may register your

product on the Internet at http://www.omnitron-systems.

com. During the warranty period, Omnitron will, at its

option, repair or replace a product which is proven to

be defective.
For warranty service, the product must be sent to

an Omnitron designated facility, at Buyer’s expense.

Omnitron will pay the shipping charge to return the

product to Buyer’s designated US address using

Omnitron’s standard shipping method.

Limitation of Warranty

The foregoing warranty shall not apply to defects

resulting from improper or inadequate use and/or

maintenance of the equipment by Buyer, Buyer-supplied

equipment, Buyer-supplied interfacing, unauthorized

modifications or tampering with equipment (including

removal of equipment cover by personnel not specifically

authorized and certified by Omnitron), or misuse, or

operating outside the environmental specification of the

product (including but not limited to voltage, ambient

temperature, radiation, unusual dust, etc.), or improper

site preparation or maintenance.
No other warranty is expressed or implied. Omnitron

specifically disclaims the implied warranties of

merchantability and fitness for any particular purpose.

Exclusive Remedies

The remedies provided herein are the Buyer’s sole and

exclusive remedies. Omnitron shall not be liable for any

direct, indirect, special, incidental, or consequential

damages, whether based on contract, tort, or any

TECHNICAL SUPPORT:

For help with this product, contact Omnitron’s Tech.

Support:
Phone:

(949) 250-6510

Fax:

(949) 250-6514

Address: Omnitron Systems Technology, Inc.

38 Tesla

Irvine, CA 92618 USA

E-mail:

[email protected]

URL:

http://www.omnitron-systems.com

SPECIFICATIONS (CONT.):

TROUBLESHOOTING GUIDE:

Problem:

The Power LED does not illuminate after installation

is complete.

Possible Causes:

A. Confirm that the power supply is connected.

B. Confirm that the correct power supply is being used.
Problem:

The Fiber Optic link LED does not illuminate after

installation is complete.
Possible Causes:

A. Confirm that the fiber optic cable is properly

connected to the miConverter Gx and the remote fiber

optic device.

B. Confirm that the fiber cable type matches the fiber

transceiver type (multimode, single-mode) on the

miConverter Gx.

C. If using a dual-fiber model, confirm that the transmitter

(Tx) is attached to the receiver side of its link partner,

and that the receiver (Rx) is attached to the transmitter.

D. If using a single-fiber model, confirm that the Tx

wavelength on the miConverter Gx matches the Rx of

the connected fiber optic device.
Problem:

The Fiber Optic link LED blinks slowly after installation

is complete, indicating connected devices are not able

to complete auto-negotiation.
Possible Causes:

A. Confirm that the miConverter Gx and the connected

fiber optic and UTP devices are set to auto-negotiation

mode. If the connected fiber device does not support

auto-negotiation, configure the miConverter to MAN

mode.

B. Confirm that the UTP cables of the miConverter Gx

and the connected fiber optic and UTP devices are

properly connected.

C. If two miConverter Gx converters are connected via

fiber, confirm that both converters have their fiber optic

ports set to auto-negotiate “AN” and their UTP ports

connected to remote devices.

D. Confirm that the connected UTP and fiber optic

devices have the same Duplex/Pause capabilities.
Problem:

The UTP link LED does not illuminate after installation

is complete.
Possible Causes:

A. Confirm that the UTP cable is connected properly

to the miConverter Gx and the attached UTP device.

B. Confirm that the UTP cable pin-out is correct

(EIA/TIA-568-A).

C. Confirm that the attached UTP device is working

properly and is capable of Gigabit Ethernet speed.
Note: If corrective actions do not resolve your

situation, please contact Omnitron Systems

Page 13

Description

1000BASE-T UTP to 1000BASE-X

Copper to Fiber Media Converter

with Auto-negotiation

Protocols

802.3ab, 1000BASE-T,

1000BASE-X

UTP Cable Type

EIA/TIA 568A/B

Category 5 and higher

Fiber Cable Type

Multimode: 50/125,

62.5/125, 100/140um

Single-mode: 9/125um

UTP Connector Type

RJ45

Fiber Connector Types

Single-Fiber: SC

Dual Fiber: ST, SC

Power Requirements

Minimum DC Power

0.5A @ 5VDC

DC Power Connector

2.5mm DC Jack - Center Positive

AC Power Adapter

[US]

100-120VAC/60Hz

0.03A @ 120VAC

AC Power Adapter

[Universal and

Country/Region Specific]

100-240VAC/50-60Hz

0.03A @ 120VAC

Dimension (WxDxH)

W:1.71" x L:4.10" x H:0.84"

Weight
without power adapter

5 oz.

with USB power adapter cable

6 oz.

with AC power adapter [US]

12 oz.

with AC power adapter

[Universal]

19 oz.

Compliance

UL, CE, FCC Class A

Temperature
Operational

0 to +50

o

C

Storage

-50 to +80

o

C

Humidity

(non-condensing)

5% to 95%

Altitude [ft]

-100m to 4000m

MTBF [hrs]
without power adapter

810,000

with US and

Country/Region Specific

power adapter

250,000

with Universal power adapter

100,000

Copyright © 2013 by Omnitron Systems Technology, Inc.

All Rights Reserved

Copyright © 2013 by Omnitron Systems Technology, Inc.

All Rights Reserved

Copyright © 2013 by Omnitron Systems Technology, Inc.

All Rights Reserved

Copyright © 2013 by Omnitron Systems Technology, Inc.

All Rights Reserved

Copyright © 2013 by Omnitron Systems Technology, Inc.

All Rights Reserved

Copyright © 2013 by Omnitron Systems Technology, Inc.

All Rights Reserved

Copyright © 2013 by Omnitron Systems Technology, Inc.

All Rights Reserved

Copyright © 2013 by Omnitron Systems Technology, Inc.

All Rights Reserved

LED INDICATORS:

Function

Color Legend Off State

On / Blinking State

Power

Amber PWR

No power

Amber = power

F/O link Act

Green F/O

No fiber

optic link

Green = link

Green rapid blink (10Hz) = data

Green slow blink (0.5Hz) = fiber

cable is connected but unable

to complete auto-negotiation

F/O Auto-Neg Green AN

Manual

mode

Auto-negotiation mode

UTP-link Act

Green UTP

No UTP

link

Green = link

Green rapid blink (10Hz) = data

Full-Half

Duplex

Green FDX

UTP is at

Half-Duplex

UTP is at Full-Duplex

Note: For additional assistance with LED

indicators, please refer to the miConverter Gx

TROUBLESHOOTING GUIDE (pp. 11-13).
