4.0 SPECIFICATIONS
Chassis Type
2-Module AC
8.5 watts
2-Module AC
16.5 watts
2-Module DC
6.6 watts
2-Module DC
16.5 watts
Model Number
Standard
Dying Gasp
8230-0
8230-1
8231-0
8231-1
8235-0
8235-1
8236-0
8236-1
Module Capacity
2
Power Supply
Capacity
Fixed Internal
Input Power
Requirements
(typical)
100 to 240VAC,
50/60Hz
0.5A @ 120VAC
100 to 240VAC,
50/60Hz
0.5A @ 120VAC
+/- 18 to 60VDC
-48VDC @ 1.0A
+/- 18 to 60VDC
-48VDC @ 2.0A
Backplane Power
2.6A @ 3.3VDC
1.5A per slot
5A @ 3.3VDC
2.5A per slot
2A @ 3.3VDC
1.5A per slot
5A @ 3.3VDC
2.5A per slot
Dimensions
W:6.7" x D:5.51" x H:1.87"
Weight
2.5 lbs
Compliance
UL, CE, FCC Class A, NEBS Level 3
Temperature
Standard: 0 to 50º C
Wide: -40 to 60º C
Storage: -40 to 80º C
Humidity
5 to 95% (non-condensing)
Altitude
-100m to 4000m
MTBF(hrs)
151,000
413,000
329,000
538,000
The 8231 and 8236 have internal temperature-controlled fans. The fan will turn on
when the chassis internal temperature is greater then ~40
o
C. Under normal operating
temperature, the fan is off.
