STR46SPVG • RIDE-ON POWER TROWEL — OPERATION AND PARTS MANUAL — REV. #2 (07/09/07) — PAGE 41
STR46SPVG — SUGGESTED SPARE PARTS
31 VANGUARD ENGINE
1 to 3 Units
Qty. P/N Description
5 ................ 2829 .............. ARMS
4 ................ 10937 ............ BELT (B-37)
2 ................ 11693 ............ BOLT BATTERY
2 ................ 8381 .............. BOOT, TOGGLE SWITCH
2 ................ 11692-1 ........ BRACKET BATTERY
1 ................ 11771 ............ BRACKET ENGINE THROTTLE CABLE
11 .............. 12771 ............ BRONZE GEAR (L.S. FOR 1-1/4 SHAFT)
1 ................ 12772 ............ BRONZE GEAR (R.S. FOR 1-1/4 SHAFT)
5 ................ 11039 ............ BUSHING
2 ................ 12460 ............ CABLE, PITCH
20 .............. 1162A ........... CAP GREASE FITTING
1 ................ 2580 .............. CHOKE CABLE
1 ................ 2673 .............. CIRCUIT BREAKER 30 AMP, 12V
1 ................ 10434 ............ CLAMP
2 ................ 820263 .......... ELEMENT, AIR CLEANER
2 ................ 821075 .......... FAN BELT
2 ................ 29509 ............ FUEL CAP STEEL TANK
1 ................ 820026 .......... FUEL FILTER
2 ................ 2618 .............. GASKET KIT
1 ................ 12908 ............ GEAR WORM
4 ................ 0189 .............. HANDLE GRIP
1 ................ 12849 ............ HEADER PIPE
2 ................ 825557 .......... HOSE
2 ................ 825133 .......... HOSE
2 ................ 29640 ............ HOUR METER
20 .............. 1876 .............. JAM NUT
1 ................ 2323 .............. KEY 1/4 X 1/4 13/16
4 ................ 11078 ............ KEYS, IGNITION (SWITCH)
2 ................ 12833 ............ KIT, BEARING (1-1/4 SHAFT)
2 ................ 2737 .............. KNOB ASSY.
1 ................ 10922 ............ LEFT-SIDE FAN
1 ................ 1617 .............. LEVER ASSY. TROWEL ADJUSTMENT
2 ................ 9005 .............. LEVER TROWEL ARM (L.S.)
2 ................ 1986 .............. LEVER TROWEL ARM (R.S.)
1 ................ 12764 ............ MAIN SHAFT, 1-1/4 DIAMETER
1 ................ 20908 ............ MUFFLER
20 .............. 1456 .............. NUT (3/8 -16)
2 ................ 491056 .......... OIL FILTER
1 ................ 9028 .............. PIN YOKE
1 ................ 10921 ............ RIGHT-SIDE FAN
2 ................ 21870 ............ SAFETY KILL SWITCH
20 .............. 0164B ........... SCREW
20 .............. 4514 .............. SCREW (HHC 1/4-20 X 5/8)
20 .............. 16602 ............ SCREW (HHC 3/8 -16 X 3/8)
20 .............. 12097 ............ SCREW (SQH 3/8-16 X 1 3/4 CONE)
20 .............. 1322 .............. SCREW ASSY., ARM RETAINING
Part numbers on this
Suggested Spare Parts
List may supercede/
replace the P/N shown in
the text pages of this
book.
NOTE
1 ................ 21861 ............ SEAT
1 ................ 12906 ............ SHAFT GEARBOX INPUT W/FAN
3 ................ 496018S ....... SPARK PLUG
2 ................ 12787 ............ SPIDER, 1-1/4 DIA. MAINSHAFT
2 ................ 12548 ............ SPRAY PUMP
2 ................ 9111 .............. SPRING (L.S.)
2 ................ 2143 .............. SPRING (R.S.)
1 ................ 11430 ............ SWITCH
2 ................ 10958 ............ SWITCH, IGNITION
1 ................ 19301 ............ TERMINAL STRIP (10-POLE)
2 ................ 2124 .............. THROTTLE CABLE
2 ................ 20938 ............ THRUST COLLAR KIT
2 ................ 4682 .............. TOGGLE SWITCH
20 .............. 0166A ........... WASHER
20 .............. 1875 .............. WASHER
20 .............. 0181B ........... WASHER 1/4 IN
10 .............. 10031 ............ WASHER 1/4 IN.
6 ................ 2509 .............. WING NUT
1 ................ 1139 .............. WOODRUFF KEY
1 ................ 12100 ............ YOKE
