WSHe/a vibraTory TruSS Screed • operaTion manual — rev. #0 (05/22/12) — page 13
SpecificatiOnS
Table 1. engine-powered Screeds
Recommended Slump 3 in (76 mm)
Max. Concrete Depth 8 in (203 mm)
Max Screed Width 65 ft (19.8 m)
model description Weight lb. (kg)
WSHE20 2 foot (.61 m) truss with eccentric shaft vibration 46 (20)
WSHE25 2.5 foot (.76 m) truss with eccentric shaft vibration 50 (23)
WSHE50 5 foot (1.5 m) truss with eccentric shaft vibration 95 (43)
WSHE75 7.5 foot (2.3 m) truss with eccentric shaft vibration 136 (62)
WSHE100 10 foot (3.1 m) truss with eccentric shaft vibration 190 (86)
accessories
model
description Weight lb. (kg)
WSHEH End handles (two each) 54 (27)
WSHW Manual Winches, set of two 42 (19)
WSHSPW(L) Self-propelled winch (left side), includes 2.5 foot truss 105 (48)
WSHSPW(R) Self-propelled winch (right side), includes 2.5 foot truss 105 (48)
WSHRBE Reinforcement bracket, engine screed 6 (2.7)
WSKITAEB Adjustable end brackets, set of two, skid type 24 (11)
WSKITAEBR Adjustable end brackets, set of two, roller type 26 (12)
WSHEKITUJ Invert/crown kit, for adjustments up to ¼-inch per foot 22 (10)
WSHEIC Invert/crown kit, for adjustments in excess of ¼-inch per foot 98 (41)
WSHEKIT9H 9 HP Engine Kit 112 (51)
WSHE50KIT9H
9 HP Engine Kit
installed on 5 foot truss section
207 (94)
WSHEKIT11H 11 HP Engine Kit 112 (51)
WSHE50KIT11H
11 HP Engine Kit
installed on 5 foot truss section
207 (94)
36243 Truss screed dolly 50 (23)
