MVH306GH PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #8 (01/31/14) — PAGE 75
GX270K1-SMX2 ENGINE — RECOIL STARTER ASSY.
RECOIL STARTER ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 28400ZE2W01ZB RECOIL STARTER AY/GX240,B ............... 1 .....................INCLUDES ITEM W/ *
2 * 28410ZE2W01ZB CASE COMP.,RECOIL STARTER 1
3 * 28421ZE2W01 PULLEY,RECOIL STARTER 1
4 * 28422ZE2W01 RATCHET,STARTER 2
5 * 28441ZE2W01 SPRING,FRICTION 1
6 * 28442ZE2W01 SPRING,STARTER RETURN 1
7 * 28443ZE2W01 SPRING,RATCHET 2
8 * 28444ZE2W01 RETAINER,SPRING 1
10 * 28461ZE2W02 GRIP,STARTER 1
11 * 28462ZE2W11 ROPE, RECOIL STARTER 1
13 * 90004ZE2W01 SCREW,CENTER 1
14 90008ZE2003 BOLT,FLANGE 6X10 3
GX270K1SMX2 — RECOIL STARTER ASSY.
