MVH306GH PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #8 (01/31/14) — PAGE 59
CYLINDER BARREL ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 12000ZH9406 BARREL ASSY.,CYLINDER ...................... 1 ...................... INCULDES ITEM W/ *
2 15510ZE2043 SWITCH ASSY,OIL LEVEL 1
3 16541ZE2010 SHAFT,GOVERNOR ARM 1
6 90131883000 BOLT,DRAIN PLUG 2
7 90446KE1000 WASHER 8.2X17X0.8 1
9 * 91201890003 OIL SEAL, 30X46X8 1
10 91353671004 O-RING 14MM 1
11 9405010000 FLANGE NUT M10 1
12 9410912000 WASHER,DRAIN PLUG M12 2
13 9425110000 PIN,LOCK 10MM 1
14 957010601200 FLANGE BOLT 6X12 2
16 34150ZH7003 ALERT UNIT, OIL 1
17 90013883000 FLANGE BOLT 6X12 1
19 90131ZE3790 DRAIN JOINT 1
20 9280012000 BOLT, DRAIN PLUG 12MM 1
GX270K1SMX2 — CYLINDER BARREL ASSY.
