MVH306GH PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #8 (01/31/14) — PAGE 33
VIBRATING PLATE ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 464117840 VIBRATING PLATE 1
2 953405840 DRAIN PLUG MI8 (H) 1
3 953402930 COPPER PACKING 19X30X1 1
4 953400270 PLUG 1/4X14 10L 1
5 953405260 PACKING 1/4 (CU) 1
6 939010260 SHOCK ABSORBER 110X60H 4
7 020316130 NUT M16 4
8 030216400 WASHER, LOCK M16 4
9 001221635 BOLT 16X35 T 4
10 001221830 BOLT 18X30 T 8
11 58407 WASHER, LOCK M18 8
12 030216400 WASHER, LOCK M16 4
15 939010010 SHOCK ABSORBER, STOPPER 45 4
16 020310080 NUT M10 4
17 031110160 WASHER, FLAT M10 4
18 030210250 WASHER, LOCK M10 4
19 464343730 COVER, VIBRATING PLATE 2
20 011008015 BOLT 8X15 T 8
21 030208200 WASHER, LOCK M8 8
31 52993 EXTENSION PLATE 2
32 012218050 BOLT 18X50 T 8
33 58407 WASHER, LOCK M18 8
VIBRATING PLATE ASSY.
