MVH306GH PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #8 (01/31/14) — PAGE 49
CAMSHAFT ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 14100ZE3020 CAMSHAFT ASSY .................................... 1 ...................... INCLUDES ITEM W/ *
2 14410ZE2013 ROD,PUSH 2
3 14431ZE2010 ARM,VALVE ROCKER 2
4 14441ZE2000 LIFTER,VALVE 2
5 14451ZE1013 PIBOT,ROCKER ARM 2
6 * 14568ZE1000 SPRING,WEIGHT RETURN 1
7 14711ZE2000 VALVE, IN. 1
8 14721ZE2000 VALVE, EX. 1
9 14751ZE2003 SPRING,VALVE 2
10 14771ZE2000 RETAINER,IN.VALVE SPRING 1
11 14773ZE2000 RETAINER,EX.VALVE SPRING 1
12 14781ZE2000 ROTATOR,VALVE 1
13 14791ZE2010 PLATE,PUSH ROD GUIDE 1
14 90012ZE0010 PIBOT BOLT 8MM 2
15 90206ZE1000 NUT,PIBOT ADJUSTING 2
16 12209ZE8003 SEAL, VALVE STEM 1
GX270K1SMX2 — CAMSHAFT ASSY.
