MVH306GH PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #8 (01/31/14) — PAGE 41
CONTROL HANDLE ASSY.
NO.
PART NO. PART NAME QTY. REMARKS
1 464343680 HANDLE BRACKET 1
2 456336420 HANDLE BRACKET (R) 1
3 012212035 BOLT 12X35 T 4
4 030212300 WASHER, LOCK M12 4
5 031112230 WASHER, FLAT M12 4
7 456336400 RUBBER COUPLING 2
8 456449940 SHOCK ABSORBER 2
9 456449930 RUBBER PLATE 2
10 001221681 BOLT 16X250 T 1
11 032124400 CONICAL SPRING WASHER M24 2
12 025306016 SPRING PIN 6X16 2
13 0401450160 WASHER, FLAT M16 2
14 020316130 NUT M16 1
15 020416100 NUT M16, H=10 1
18 455434950 SPINDLE 1
19 455010030 KNOB 1
20 939010060 SHOCK ABSORBER 1
21 020310080 NUT M10, H=6 1
22 020412070 NUT M12, H=7 1
23 022411635 WING NUT M16 1
25 954404230 CLAMP SA120-18 1
26 011206020 BOLT 6X20 T 1
27 030206150 WASHER, LOCK M6 1
28 952404470 WASHER, FLAT M6 1
29 020106050 NUT M6 1
34 501402870 HANDLE STOPPER 1
35 501402880 SPRING/HANDLE (1.4X18X44) 1
36 959403460 BALL GRIP 32D-M10 1
37 020310080 NUT M10, H=6 1
38 456449980 RUBBER PACKING 9D-20D-5T 1
39 953405260 PACKING 1/4 (CU) 1
40 031110160 WASHER, FLAT M10 1
43 464343690 HANDLE COVER 1
44 0105050616 BOLT 6X15 T 6
45 030206150 WASHER, LOCK M6 6
46 952404470 WASHER, FLAT M6 6
47 464457710 PACKING A, HANDLE COVER 1
48 464457720 PACKING B, HANDLE COVER 1
49 454010020 CLAMP TC-100 1
CONTROL HANDLE ASSY.
