MVH306GH PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #8 (01/31/14) — PAGE 35
BASE & ENGINE ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 464117850 BASE 1
2 912227003 ENGINE ASSY., GX270K1SMX2 (HONDA) 1
3 0105051045 BOLT 10X45 T 4
4 030210250 WASHER, LOCK M10 4
5 031110160 WASHER, FLAT M10 4
6 464216580 BELT COVER (IN) 1
7 001121025 BOLT 8X25 T 4
8 030210250 WASHER, LOCK M10 4
9 031110160 WASHER, FLAT M10 4
10 464343670 DUST-PROOF SPONGE (IN) 1
11 464457360 SPACER 1
12 456343340 CLUTCH ASSY./CHM03/W.FAN 1
13 951400110 KEY 7X7X35 1
14 952400690 WASHER 9X35X4.5 1
15 001220830 BOLT 8X30 T 1
16 030208200 WASHER, LOCK M8 1
17 464216640 DUST-PROOF COVER 1
18 092006010 FLAT HEAD SCREW 6X10 3
19 464343660 DUST-PROOF SPONGE (OUT) 1
20 464216590 BELT COVER (OUT) 1
21 001521050 SOCKET HEAD BOLT 10X50 T 4
26 464457430 SPACER, ENGINE 2
35 464117920 RUBBER COVER (GUARD FRAME) 1
36 456449950 PLATE, COVER 1
37 011208030 BOLT 8X30 T 1
38 030208200 WASHER, LOCK M8 3
39 031108160 WASHER, FLAT M8 3
40 022710809 NYLON NUT M8 3
BASE AND ENGINE ASSY.
