MVH306GH PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #8 (01/31/14) — PAGE 37
MVH306GH — BASE AND ENGINE ASSY. (CONTINUED)
BASE AND ENGINE ASSY. (CONTINUED)
NO. PART NO. PART NAME QTY. REMARKS
41 459010060 UNION TIP, DRAIN 1
42 459010070 DRAIN HOSE 1
43 459010090 HOSE BAND 2
44 459010080 GASKET(OIL DRAIN) 2
45 0401140030 PLUG 1
46 464457380 DRAIN JOINT 1
47 014208020 BOLT 8X20 T 1
48 030208200 WASHER, LOCK M8 1
51 464117900 GUARD HOOK 1
52 012214030 BOLT 14X30 T 4
53 030214350 WASHER, LOCK M14 4
59 90131ZE3790 DRAIN JOINT 1
60 9410912000 WASHER, DRAIN PLUG M12 1
61 070200363 V-BELT 1
62 0830000010 COIL SPRING 1
63 151010680 CLAMP CP. 1
64 58151 WASHER, FLAT M5 1
70 959407260 CLIP D6 (FOR M10) 1
71 001221015 BOLT 10X15 T 1
72 030210250 WASHER, LOCK M10 1
BASE AND ENGINE ASSY.
