MVH306GH PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #8 (01/31/14) — PAGE 61
CYLINDER HEAD ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 12200ZH9000 HEAD COMP.,CYLINDER ......................... 1 ...................... INCULDES ITEM W/ *
2 * 12204ZE2306 GUIDE,IN.VALVE(OVERSIZE) 1
3 * 12205ZE2305 GUIDE,EX.VALVE(OVERSIZE) 1
4 * 12216ZE2300 CLIP,VALVE GUIDE 1
5 12251ZH9000 GASKET, CYLINDER HEAD 1
6 12310ZE2020 COVER COMP.,HEAD 1
7 950051110030 TUBE,11X100 1
8 12391ZE2020 PACKING,HEAD COVER 1
9 14775ZE2010 SEAT,VALVE SPRING 1
11 90014ZE2000 BOLT,HEAD COVER 1
12 90042ZE2000 BOLT,STUD 8X123 2
13 92900080320E BOLT,STUD 8X32 2
14 90441ZE2010 WASHER COMP.,HEAD COVER 1
15 9430112200 PIN,DOWEL 12X20 2
16 957251008000 BOLT,FLANGE 10X80 4
17 9807955846 PLUG, SPARK (BPR5ES) 1
GX270K1SMX2 — CYLINDER HEAD ASSY.
