MVH306GH PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #8 (01/31/14) — PAGE 53
CONTROL ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 16551ZE2000 ARM, GOVERNOR 1
2 16555ZE2000 ROD, GOVERNOR 1
3 16561ZE2000 SPRING, GOVERNOR 1
4 16562ZE2000 SPRING, THROTTLE RETURN 1
6 16570ZE2W10 CONTROL ASSY.(REMOTE) ..................... 1 ...................... INCLUDES ITEM W/ *
10 * 16571ZE2W00 LEVER, CONTROL 1
11 * 16574ZE1000 LEVER SPRING 1
12 * 16575ZE2W00 WASHER,CONTROL LEVER 1
13 * 16576891000 HOLDER,CABLE 1
15 * 16578ZE1000 SPACER,CONTROL LEVER 1
16 * 16581ZE2W00 BASE COMP.,CONTROL 1
17 * 16584883300 ADJUSTING SPRING 1
19 * 16592883310 SPRING,CABLE RETURN 1
20 * 16594883010 HOLDER, WIRE 1
24 90013883000 FLANGE BOLT 6X12 2
25 90015ZE5010 BOLT, GOVERNOR ARM 1
27 * 90114SA0000 LOCK NUT 6MM 1
28 * 90605230000 CIR CLIP 1
30 * 93500040060H SCREW 4X6 1
32 * 93500050280A SCREW, PAN 5X28 1
33 * 93500050160A SCREW 5X16 1
35 9405006000 FLANGE NUT 6MM 1
GX270K1SMX2 — CONTROL ASSY.
