MVH306GH PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #8 (01/31/14) — PAGE 51
CARBURETOR ASSY.
NO.
PART NO.
PART NAME
QTY.
REMARKS
1
*
%
16010ZE2812
GASKET SET
1
2
*
16011ZA0931
VALVE SET,FLOAT
1
3
*
16013ZA0931
FLOAT SET
1
5
*
16015ZE8005
CHAMBER SET,FLOAT ............................. 1 ...................... INCLUDES ITEM W/%
8
*
16028ZE0005
SCREW SET
1
9
*
16044ZE2005
CHOKE SET
1
10
16100ZH9W21
CARBURETOR ASSY. (BE75B) ................ 1 ...................... INCLUDES ITEM W/
*
11
*
16124ZE0005
SCREW, THROTTLE STOP
1
13
*
16166ZH9W20
NOZZLE, MAINE
1
14
*
16173001004
PACKING,CUP
1
15
16211ZE2000
INSULATOR, CARBURETOR
1
16
16220ZA0702
SPACER COMP.,CARBURETOR
1
17
16221ZA0800
PACKING, CARBURETOR
1
18
16223ZA0800
PACKING, INSULATOR
1
19
16610ZE1000
CHOKE LEVER COMP. ............................. 1 ...................... INCLUDES ITEM W/
+
20
16953ZE1812
LEVER,COCK
1
21
*
16954ZE1812
PLATE,LEVER SETTING
1
23
*
16956ZE1811
SPRING,COCK LEVER
1
24
*
16957ZE1812
PACKING,FUEL COCK
1
25
*
16967ZE0811
CUP,FUEL STRAINER
1
26
*
93500030061H
SCREW 3X6
2
27
+
9430520122
SPRING PIN 2X12
1
28
*
99101ZH80800
JET, MAIN, #80
1
29
*
99204ZE20400
JET SET,PILOT, #40
1
30
*
16016ZH7W01
SCREW SET
1
31
*
% 16024ZE1811
DRAIN SCREW SET
1
32
*
16172ZE3W10
COLLAR SET
1
GX270K1SMX2 — CARBURETOR ASSY.
