MVH306GH PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #8 (01/31/14) — PAGE 71
MUFFLER ASSY.
NO. PART NO. PART NAME QTY. REMARKS
2 18310ZE2W00 MUFFLER COMP. 1
3 18320ZE2W01 PROTECTOR COMP.,MUFFLER 1
4 18323ZE2W00 PROTECTOR, EXHAUST PIPE 1
5 18330ZE2W00 PIPE,EXHAUST 1
7 18333ZE3800 GASKET 1
8 18355ZE2010 ARRESTER, SPARK 1
9 18381ZE2W10 GASKET,MUFFLER(ARRESTER) 1
18 90013883000 FLANGE BOLT 6X12 1
19 90050ZE1000 TAPPING SCREW 5X8 6
26 9405008000 FLANGE NUT M8 3
29 90050ZE1000 TAPPING SCREW 5X8 1
GX270K1SMX2 — MUFFLER ASSY.
