MVH306GH PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #8 (01/31/14) — PAGE 43
CONTROL HANDLE ASSY.
NO. PART NO. PART NAME QTY. REMARKS
61 464117890 COLUMN, HANDLE 1
64 464216630 TRAVEL LEVER 1
65 464457400 HANDLE BOSS 1
66 012010030 BOLT 10X30 T 2
67 030210250 WASHER, LOCK M10 2
68 464216620 HANDLE W/RUBBER GRIP 1
69 030210250 WASHER, LOCK M10 2
70 031110160 WASHER, FLAT M10 2
71 020310080 NUT M10 2
72 011208025 BOLT 8X25 T 2
73 030208200 WASHER, LOCK 2
80 464457340 THROTTLE LEVER 1
81 959403840 BAR GRIP I.D. 12 MM 1
82 464457420 COVER, THROTTLE 1
83 464457350 ARM, THROTTLE 1
84 001520820 SOCKET HEAD BOLT 8X20 T 1
85 031116260 WASHER, FLAT 1
86 458460660 WASHER 16.4-35-0.6 2
87 033910080 CONICAL SW 16.3 X 31.5 X 1.2 3
88 464457440 STEEL BALL D6 (SUJ) 1
89 464010010 DRY BUSHING/ LBF-1620 1
90 001220625 BOLT 6X25 T 2
91 020306050 NUT M6 2
93 464010020 ROD END M5 1
94 001520520 SOCKET HEAD BOLT 5X20 T 1
95 031105080 WASHER, FLAT M5 1
96 20305040 NUT M5 1
99 954002270 OIL HOSE W/SPRING 1/4 X 920 1
101 956100055 THROTTLE WIRE 1
103 454010020 CLAMP TC-100 1
104 959021815 SPRIAL TUBE 6D-330L 1
104 959021810 SPRIAL TUBE KEP6/ L=500 1
CONTROL HANDLE ASSY.
