MVH306GH PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #8 (01/31/14) — PAGE 57
CRANKSHAFT ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 13310ZH9000 CRANK SHAFT COMP. ............................. 1 ...................... INCULDES ITEM W/ *
9 92101080250A BOLT 8X25 1
11 90534706010 WASHER,LOCK 8MM 1
12 951400110 KEY 7X7X35 1
13 * 91001ZH9003 BEARING, BALL (6206 SH) 1
GX270K1SMX2 — CRANKSHAFT ASSY.
