MVH150VD2 PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (10/10/08) — PAGE 57
YANMAR L48V6AF3R4AAW4 — COOLING/STARTING DEVICE ASSY
NO PART NO PART NAME QTY. REMARKS
1 11429945210 CYLINDER COVER 1
2 26106060122 BOLT M 6X12 PLATED 1
4 11429545100 COOLING FAN CASE 1
5 11429945300 CUSHION RUBBER 4
6 11429945310 FAN CASE COLLAR 4
7 11429945330 FAN CASE SEAL 1
8 11429945350 FAN CASE BOLT 4
10 11429976250 RECOIL STARTER (D) ASSY. .....................1 ................INCLUDES ITEMS W/ *
11 * 11429976500 STARTER CASE 1
13 * 11429976520 REEL 1
15 * 11439976530 RATCHET 1
17 * 11439976540 SPIRAL SPRING 1
19 * 11439975550 RATCHET COVER 1
20 * 11439976560 SPRING 1
21 * 11439976570 RETURN SPRING 1
22 * 11439976580 SCREW 1
23 * 11439976620 STARTER KNOB 1
24 * 11429976630 STARTER ROPE 1
25 11429976590 STARTER PULLEY 1
26 26106060082 BOLT M 6X8 PLATED 4
27 26106060122 BOLT M 6X12 PLATED 3
29 11429976600 PLUNGER 1
30 11429976610 PLUNGER HOLDER 1
