MVH150VD2 PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (10/10/08) — PAGE 51
YANMAR L48V6AF3R4AAW4 — CRANKSHAFT AND CAMSHAFT ASSY
NO PART NO PART NAME QTY. REMARKS
1 71429514580 CAMSHAFT (D) ASSY. 1
6 11429914200 TAPPET 2
7 11477114260 TAPPET, F.O. 1
8 11425014451 PUSH ROD 2
10 71477221701 CRANKSHAFT ASSY. 1
19 11429921220 NUT 1
20 11429921550 FLYWHEEL WASHER 1
21 22512040120 KEY 4X 12 1
24 11429921590 FLYWHEEL ASSY. .......................................1 ................INCLUDES ITEMS W/ *
27 * 11426221600 RING GEAR 1
61 71477028531 SHAFT ASSY. BEARING 1
66 24101062020 BEARING 6202 2
67 16031014550 WASHER 1
68 22512050300 KEY 5X30 1
69 26106080202 BOLT M8 X20 PLATED 1
