MVH150VD2 PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (10/10/08) — PAGE 11
SPECIFICATIONS
MVH150VD2 Specifi cations Table 1.
Centrifugal Force 6,070 lbf (27 kN)
Vibration Frequency 5400 vpm (90 Hz)
Traveling Speed 0 to 82 ft/min (0 to 25 m/min)
Plate Size (L x W) 27.6 x 16.9 in (700 x 430 mm)
Max. Area of Compaction 6,942 sq. ft./h (645 sq. meters/h)
Operating Weight 331 lbs. ( 150 kg)
Vibrating Oil Capacity 0.37 quart (0.35 liter)
Engine Specifi cations Table 2.
Model YANMAR L48V6AF3R4AAW4
Type
Air-cooled, 4-cycle
Diesel Engine
Bore X Stroke
2.76 in. X 2.24 in.
(70 mm x 57 mm.)
Displacement 13.4 cu. in. (219 cc)
Max Power Output 4.4 HP (3.3 KW) @ 4,000 R.P.M.
Fuel Tank Capacity 2.5 quarts (2.4 liters
Fuel Diesel
Operating Speed 3,600 rpm
Lube Oil Capacity 0.85 quarts (0.8 liters)
Starting Method Recoil Start
