Multiquip MVH150VD2 - Manual (Page 43)

MVH150VD2 PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (10/10/08) — PAGE 43
YANMAR L48V6AF3R4AAW4 — CYLINDER BLOCK ASSY
NO PART NO PART NAME QTY. REMARKS
1 11429501050 CYLINDER BLOCK ASSY. 1
5 11439901700 STARTER COVER 1
6 26106100122 BOLT M10X 12 PLATED 2
7 24162152112 NEEDLE BEARING 1
8 26106080122 BOLT M 8X 12 PLATED 1
9 11429901200 CYLINDER HEAD BOLT A 2
10 11429901210 CYLINDER HEAD BOLT B 2
11 11429901220 CYLINDER HEAD NUT A 2
12 11429901230 CYLINDER HEAD NUT B 2
13 12495001250 WASHER 4
14 11429501330 CYLINDER HEAD GASKET ASSY. 1
20 11429901380 O- RING 1
21 11429901600 PIN 8X12 2
22 11429901800 SHIM SET 1
33 11429901830 COVER, (FO PUMP) 1
34 11425001841 GASKET 1
35 22312040080 PIN 4X8 STRAIGHT 2
36 26226060182 STUD M 6X 18 PLATED 1
37 26226060222 STUD M 6X 22 PLATED 2
38 26366060002 NUT M 6 3
39 11429901410 CRANK CASE GASKET 1
40 11428401452 CRANK CASE COVER ...............................1 ................INCLUDES ITEMS W/ *
45 * 11425002100 MAIN BEARING US=STD. 1
45 11425002200 BEARING US=0.25, MAIN 1
45 11425002210 BEARING US=0.50, MAIN 1
48 11429935150 L.O. INLET PIPE 1
49 26106060252 BOLT M 6X 25 PLATED 14
50 26106080352 BOLT M 8X 35 PLATED 1
53 11429901690 PLUG M16 2
54 11429901760 CAP, W/LUBE OIL GAUGE .........................1 ................INCLUDES ITEMS W/#
56# 11429901950 O- RING 1
57 22190160002 SEAL WASHER 16S 2
58 11429902030 RETAINER 1
59 11425002113 BALL BEARING 1
60 11429902220 OIL SEAL 1
61 16021002220 OIL SEAL 1
62 23876010000 PLUG PT 1/8, SCREW 1
