Multiquip MVH150VD2 - Manual (Page 47)

MVH150VD2 PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (10/10/08) — PAGE 47
YANMAR L48V6AF3R4AAW4 — AIR CLEANER ASSY
NO PART NO PART NAME QTY. REMARKS
1 11429912210 GASKET, AIR CLEANER 1
2 11429912300 U- NUT 3
3 11428812511 CLEANER, AIR ASSY. ................................1 ................INCLUDES ITEMS W/ *
4 * 11465007450 LABEL, AIR CLEANER 1
5 * 11428812520 COVER COMPL. 1
6 * 11428812532 CASE, AIR CLEANER 1
7 * 11425212560 SEAL WASHER M8 1
8 * 11465012590 ELEMENT W/ PRE- FILTER........................1 ................INCLUDES ITEMS W/ $
10 * $ 11465012550 PRE- FILTER 1
11 11425212550 WING NUT M8
13 11477112010 INTAKE MANIFOLD 1
14 11477112200 AIR INTAKE GASKET 1
15 26106060252 BOLT M 6X 25 PLATED 2
16 26226060142 STUD M 6X14 PLATED 1
17 26226060552 STUD M 6X 55 2
