MVH150VD2 PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (10/10/08) — PAGE 45
YANMAR L48V6AF3R4AAW4 — CYLINDER HEAD ASSY
NO PART NO PART NAME QTY. REMARKS
1 11477111020 CYLINDER HEAD 1
6 11477111100 SUCTION VALVE 1
7 11477111110 EXHAUST VALVE 1
8 11429911120 VALVE SPRING 2
9 1142511180 SPRING RETAINER 2
10 27310055001 COTTER 2
11 22351040008 SPRING PIN 4X8 1
12 11477111250 ARM SUPPORT CAM .................................1 ................INCLUDES ITEMS W/ *
13 * 11477111260 ROCKER ARM SUPPORT 1
14 * 11477111650 INTAKE ARM ASSY. ....................................1 ................INCLUDES ITEMS W/ %
16 * % 11425011240 VALVE ADJUST. SCREW 1
17 * % 26856060002 LOCK NUT 6 1
18 * 11477111660 EXHAUST ARM ASSY. ................................1 ................INCLUDES ITEMS W/ $
20 * $ 11425011240 VALVE ADJUST. SCREW 1
21 * $ 26856060002 LOCK NUT 6 1
22* 22242000120 CIR CLIP 12 2
23 11425011340 VALVE STEM SEAR 2
24 11926011370 VALVE CAP 2
25 11477111461 NOZZLE GASKET 1
26 11429511470 NOZZLE SPACER 1
27 11429911600 VALVE SPRING WASHER 2
28 11429911901 NOZZLE RETAINER 1
29 26106060452 BOLT M 6X45 PLATED 2
30 11471811910 STUD BOLT M6X65 2
31 26366060002 NUT M 6 2
32 11477111310 BONNET GASKET 1
33 11429511951 BONNET COMPLETE .................................1 ................INCLUDES ITEMS W/ #
35# 11425003591 SHAFT ASSY. DECOMP. 1
38# 11429903640 SPRING, DECOMP. 1
39# 22312030160 PARALLEL PIN 3X16 1
55 26106060552 BOLT M 6X 55 PLATED 3
