MVH150VD2 PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (10/10/08) — PAGE 33
BODY ASSY
NO PART NO PART NAME QTY. REMARKS
1 459116670 BASE 1
2 914410024 ENGINE ASSY, L48V6AF3R4AAW4 1
3 001221040 BOLT 10X40 T 3
3-1 001221035 BOLT 10X35 T 1
4 030210250 WASHER, LOCK M10 4
5 031110160 WASHER, FLAT M10 4
6 459216380 BELT COVER PLATE 1
7 001220820 BOLT 8X20 T 4
8 030208200 WASHER, LOCK M8 4
11 458451370 SPACER 202512 1
12 458337770 CLUTCH ASSY A1-124-20 ................................1.................. INCLUDES ITEMS W/ *
12-1 * 941040510 CLUTCH SHAFT S20D-45 1
12-2 * 941010390 CLUTCH PULLEY A1-124 1
12-3 * 941020030 CLUTCH SHOE T90T 3
12-4 * 941030230 CLUTCH SPRING 2
12-5 * 080200300 STOP RING S-30 1
12-6 * 080600550 STOP RING AR-55 1
12-7 * 046006006 BEARING 6006DDU 1
13 951406780 KEY 5X5X30 RR 1
14 458451380 CLUTCH WASHER 1
15 001520825 SOCKET HEAD BOLT 8X25 T 1
16 070100352 V-BELT A-35 BLUE/RPF3350 1
17 459214530 DUST COVER 1
18 092006010 FLAT HEAD SCREW 6X10 2
19 459338190 SPONGE, DUST COVER 1
20 459115420 BELT COVER (UPPER) 1
21 001520852 SOCKET HEAD BOLT 8X60 T 3
22 001520820 SOCKET HEAD BOLT 8X20 T 1
35 458450830 RUBBER COVER 1
36 458450810 PLATE, RUBBER COVER 1
37 001220825 BOLT 8X25 T 2
38 030208200 WASHER, LOCK M8 2
39 031108160 WASHER, FLAT M8 2
40 022710809 NYLON NUT M8 2
41 2556390111 UNION 1
42 2556380103 DRAIN HOSE 1
43 0091720000 HOSE CLAMP 2
44 0211140020 GASKET 2
45 0401140030 PLUG 1
46 459454460 JOINT 1
47 001220820 BOLT 8X20 T 1
48 030208200 WASHER, LOCK M8 1
49 221901600002 SEAL WASHER 16S 1
51 459119660 GUARD FRAME 1
52 001221225 BOLT 12X25 T 4
53 030212300 WASHER, LOCK M12 4
56 16080278260 CLAMP 1
57 001220610 BOLT 6X10 T 1
58 030206150 WASHER, LOCK M6 1
59 459455560 UNION, OIL DRAIN 1
60 930103521 SHOCK ABSORBER ME35 15X15 1
61 458347660 LOCK LEVER 1
62 030208200 WASHER, LOCK M8 1
63 020408050 NUT M8, H=5 2
64 001520830 SOCKET HEAD BOLT 8X30 T 1
