MVH150VD2 PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (10/10/08) — PAGE 35
VIBRATOR ASSY
NO PART NO PART NAME QTY. REMARKS
A 459910013 VIBRATOR ASSY ........................................1 ................INCLUDES ITEMS W/ *
1 * 458115150 VIBRATING CASE 1
2 * 047920090 ROLLER BEARING NJ307MC4 4
3 * 458337700 ROTARY SHAFT, DRIVE 1
4 * 458342580 ROTARY SHAFT, DRIVEN/NEW 1
5 * 080200350 STOP RING S35 8
6 * 951405460 KEY 10X8X19 RR 1
9 * 040306907 BEARING 6907C3 2
11 * 458337730 PISTON ROD 1
12 * 025508050 PIN 8X50 1
13 * 042506000 BEARING 6000ZZSG 2
14 * 080200100 STOP RING S10 1
15 * 455435051 PISTON, 22.4D 1
16 * 455010070 PACKING USH22.4X30X5 1
17 * 080100260 STOP RING R26 1
18 * 459451850 ECCENTRIC ROTATOR 4
19 * 009120306 SOCKET HEAD BOLT 10X30T 4
20 * 060202040 OIL SEAL SC28458 1
21 * 458337740 BEARING COVER 1
22 * 031108160 WASHER, FLAT M8 4
23 * 030208200 WASHER, LOCK M8 4
24 * 031108160 WASHER, FLAT M8 4
25 * 953405580 SEAL CAP SC458 1
26 * 458214370 CYLINDER 1
27 * 001220820 BOLT 8X20 T 4
28 * 030208200 WASHER, LOCK M8 4
29 * 031108160 WASHER, FLAT M8 4
30 * 460347340 GEAR (DRIVE) 1
31 * 458342590 GEAR (DRIVEN) 1
32 * 001200812 BOLT 8X12 1
33 * 953404600 COPPER PACKING 8X16X2 1
34 * 954010020 CONNECTOR PT, PF1/4 1
35 459341310 PULLEY 90D W/ FAN 1
36 * 951400990 KEY 7X7X20 1
37 459452100 WASHER 9X(2430)X17 1
38 001220835 BOLT 8X35 T 1
39 030208200 WASHER, LOCK M8 1
40 * 001221240 BOLT 12X40 T 2
41 001221264 BOLT 12X120 T 6
42 030212300 WASHER, LOCK M12 8
43 031112230 WASHER, FLAT M12 8
45 459214510 BELT COVER (LOWER) 1
46 001520645 SOCKET HEAD BOLT 6X45 T 5
48 * 952406180 SHIM 70800.2T 1
