MVH150VD2 PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (10/10/08) — PAGE 37
CONTROL ASSY
NO PART NO PART NAME QTY. REMARKS
7 031110160 WASHER, FLAT M10 1
8 939010320 STOPPER RUBBER 45X36H 1
9 020410060 NUT M10, H=6 1
10 030210250 WASHER, LOCK M10 1
11 458338001 PUMP ASSY 1
12 459337960 TRAVEL LEVER 1
13 001520820 SOCKET HEAD BOLT 8X20 T 2
14 458451420 COLLAR 1
15 033910030 WAVE WASHER 15.5X20X0.3 4
17 022710809 NYLON NUT M8 2
18 030208200 WASHER, LOCK M8 2
19 954002860 OIL HOSE 1040L 1
20 954404230 CLAMP SA12018 1
21 001220625 BOLT 6X25 T 1
22 020306050 NUT M6 1
23 030206150 WASHER, LOCK M6 1
24 031106100 WASHER, FLAT M6 1
28 458451630 BREATHER CAP 1
29 458347640 HANDLE BRACKET, L 1
30 458347650 HANDLE BRACKET, R 1
31 458461430 LOCK CATCH 1
32 009120408 SUNK HEAD BOLT 8X20 T 3
35 001221230 BOLT 12X30 T 4
36 030212300 WASHER, LOCK M12 4
40 458217830 HANDLE GRIP 1
41 001220825 BOLT 8X25 T 2
42 030208200 WASHER, LOCK M8 2
45 953406280 GROMMET NG790 1
49 458461450 MOUNT NUT, HANDLE 1
