MVH150VD2 PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (10/10/08) — PAGE 39
CONTROL ASSY
CONTINUED
NO
PART NO PART NAME QTY. REMARKS
A 362910060 THROTTLE LEVER ASSY ..........................1 ................INCLUDES ITEMS W/ *
50 001520610 SOCKET HEAD BOLT 6X10 T 1
51 458461440 MOUNT NUT, THROTTLE 1
52 001520510 SOCKET HEAD BOLT 5X10 T 1
53 463455950 SPACER, THROTTLE 1
54 * 362341550 THROTTLE BODY 1
55 * 362910090 THROTTLE,GEAR CP,W/ BOLT 1
56 * 362455630 THROTTLE LEVER 1
57 * 362455620 SLIDER 1
58 * 050100450 O-RING G45 1
59 * 050200100 O-RING P10 1
60 * 031110160 WASHER, FLAT M10 3
61 * 032110180 CONICAL SPRING WASHER M10 2
62 * 096206006 SOCKET HEAD SCREW 6X6 1
63 * 020410060 NUT M10, H=6 1
64 * 022131008 CAP NUT M10 1
65 * 096208020 SOCKET HEAD SCREW 8X20 1
66 * 020408050 NUT M8, H=5 1
68 001220625 BOLT 6X25 T 2
69 030206150 WASHER, LOCK M6 2
70 031106100 WASHER, FLAT M6 2
81 956100047 THROTTLE WIRE 845-925 1
82 16067066350 WASHER, THROTTLE 1
83 26756060002 LOCK NUT M6 PLATED 1
84 26366060002 NUT M6 1
90 930106511 SHOCK ABSORBER ME65 M12 2
91 030212300 WASHER, LOCK M12 4
92 020312100 NUT M12 4
93 939010310 STOPPER RUBBER 45X33H 2
94 030210250 WASHER, LOCK M10 2
95 020410060 NUT M10, H=6 2
