Operation, Operation 75 – MTS Criterion 60 - Manual User Manual
Page 75
MTS Criterion™ Series 60 Product Manual
Operation
75
Operation
This section describes the actions performed during normal, day-to-day operation
of the MTS Criterion Series 60 systems. For information on using the system in
actual testing, refer to the testing software manual.
Contents
Travel Limit Switches (Physical Limits) 76
Integrated Operations Platform Control Panel 78
Operating the test system requires specialized knowledge.
If unqualified personnel operate the system, personal injury or equipment
damage an occur.
Ensure that the frame is only operated by qualified, trained personnel.
Keep bystanders away during system operation.
WARNING
