Page 67
Controller Connections
MTS Criterion™ Series 60 Product Manual
Installation
67
J5 Digital I/O
Digital I/O signals include three optically isolated inputs, three optically isolated
outputs, and 12 V power. Functions of each digital input or output are software
selectable. J5 should be connected to J12 to make the controller board and
interface board communicate with each other. Pin assignment is as follows:
J6 and J7 Monitor
Two monitor connectors are provided. There are several possible uses for analog
monitor outputs: external data acquisition, tuning, troubleshooting, and so forth.
For tuning, it is desirable to monitor command and feedback, or command and
error, simultaneously while changing the controller parameters. Therefore, two
monitor outputs are provided. Specifics for these connectors are:
•
Analog +/-10.5 V
•
Calibrated to +/-10 V
•
16-bit resolution minimum
•
BNC connectors
Pin Assignment
P
IN
S
IGNAL
1
In 1+
2
In 2+
3
In 3+
4
Out 1+
5
Out 2+
6
Out 3+
7
No Contact
8
+12V
9
In 1-
10
In 2-
11
In 3-
12
Out 1-
13
Out 2-
14
Out 3-
15
Analog GND
