Station, Station 32 – MTS Multi-Pump Control Manager User Manual
Page 32

Multi-Pump Control Manager
32
Station
Operation
Station
The Station Flow Manager screen allows you to control the flow demand inputs.
5
Serial Number, HMI Software
Part Number, PLC Software Part
Number
Information fields.
6
System ROD Setup
(flow sensor must be present
and enabled)
These pushbutton/indicators [Minimum Flow, Flow Buffer, On
Delay (sec), and Off Delay (sec)] allow you to set up the Run On
Demand parameters. Refer to
on page 35 and
on page 36 for a detailed description.
Item Name
Description
Item
Description
1
Display. Clicking this field shows an alpha-numeric keypad that
lets you enter a name for the station.
2
Pushbutton/Indicator. Used to turn on/off the associated channel.
Gray = off. Green = on. Green with hash marks = the channel is
controlled by DIO. These only function with the system in the
Auto mode.
