EXPLODED VIEW AND PARTS LIST
EA14
Screw, 5/16-18 x 2” Hex Head Tap
1
157938
EA15
Pin, Split Wrist
1
151358
EA16
Bushing, Plastic
2
156441
EA17
Label, Caution, Owners Manual 4 x 1 1/4
1
155576
EA18
Label, Caution, Overtension of Belts
1
155583
EA19
Washer, 3/8 Split Lock
2
150925
EA20
Motor Mount, Pivot Shaft
1
154147
EA21
Spring, Torsion Pivot Shaft
1
150587
EA22
Collar, Pivot Shaft
2
140012
EB
Assembly, Cutting Head DP-2001
1
n/a
EB1
Head, Brick Saw, Die Cast, Motor Mounting
1
160346-OR
EB2
Clamp, Brick Saw Die Cast Motor Mounting Head
2
160397-OR
EB3
Housing, Pivot Shaft
1
157979
EB4
Screw, 5/16-18 x 2 1/2, Hex Head Tap
4
151748
EB5
Shaft, Threaded
1
150585
EB6
Bearing, Pivot Shaft
2
140004
EB7
Handle
1
139931
EB8
Grip, Handle
1
139949
EB9
Screw, 3/8-16 x ¾, Hex Head Cap
2
152507
EB10
Strap, Motor Adjustment
1
150584
EB11
Screw, 3/8-16 x 3 ½ Hex Head Cap
1
153147
EB12
Washer, 3/8 SAE Flat
1
150923
EB13
Screw, 5/16-18 x 1 3/4, Hex Head Cap
4
160948
EB14
Screw, 5/16-18 x 2” Hex Head Tap
1
157938
EB15
Pin, Split Wrist
1
151358
EB16
Bushing, Plastic
2
156441
EB17
Label, Caution, Owners Manual 4 x 1 1/4
1
155576
EB18
Label, Caution, Overtension of Belts
1
155583
EB19
Washer, 3/8 Split Lock
2
150925
EB20
Motor Mount, Pivot Shaft
1
154147
EB21
Spring, Torsion Pivot Shaft
1
150587
EB22
Collar, Pivot Shaft
2
140012
F
Assembly, Blade Shaft MK2000
1
154636
F1
Casting, Blade Shaft-Arbor, Complete
1
153791
F2
Bearing, Blade Shaft MK-2000, 5000
2
154594
F3 Shaft,
Blade
1
154639
F4
Flange, Inner
Steel, 12L14 3-5/8 Diameter
1
.08’
154640
154260
F5
Flange, Outer 14 Inch M-Saw
Steel, 12L14 3-5/8 Diameter
1
.16’
132290
154260
F6
Screw, 1/2-20 x 1-1/4, Hex Head
1
152122
F7
Pin, Arbor Alignment
2
153946
F8
Screw, 5/16-18 x 2-1/2
4
101675
F9
Washer, 5/16 Split Lock
4
151747
F10
Washer, 5/16 SAE Flat
4
151754
F11
Pulley, 1 Groove 2-1/2OD x 3/4 ID
1
133140
