6 Opening the Application Sample
The Application Sample includes a sample program with three axes and a predefined visualisation.
General procedure
The main steps are presented in the table below:
The commissioning steps in detail
The following section provides a detailed description of every commissioning step.
Please follow the instructions below carefully to commission your automation system.
Step Activity
1st Creating a new project - opening the Application Sample ( 19)
2nd Updating the Controller in the project (optional) ( 19)
3rd Going online ( 20)
4th Loading and starting the PLC program ( 20)
5th Getting started - operating the Application Sample ( 22)

Further information about the parameterisation and configuration of the is
provided in the following communication manuals:
• "Controller-based Automation" EtherCAT - commissioning & configuration
