Overview - The structure of the Application Sample
A11_ProgramCalls
14
Lenze · Servo Inverter i700 | Application Sample · DMS 1.0 EN - 09/2012 - TD11
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.1
A11_ProgramCalls
5.2
A20_Visualisation
The
PC_Task_High program calls all
high-priority programs of the
application.
B1_Info: "Getting started"
• ... contains the stored information on the
structure and use of the Application Sample.
B2_AxisBasicControl
• ... contains the visualisations for the individual
instances of the L_SMC_AxisBasicControl
block.
B3_CyclicMove
• ... contains the visualisation of the CyclicMove
block.
B4_Gearing
• ... contains the visualisation of the Gearing
block.
B5_BrakeControl
• ... contains the visualisation of the
BrakeControl block.
B6_EtherCATDiagnostic
• ... contains the visualisation of the EtherCAT
diagnostic of the application.
Main calls the user interface of the main page
of the visualisation which serves to run the entire
visualisation.
• ... contains all visualisations of subfolders B1-
B6.
