What is the Application Sample?
Overview of the features of the Application Sample
12
Lenze · Servo Inverter i700 | Application Sample · DMS 1.0 EN - 09/2012 - TD11
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
4.2
Overview of the features of the Application Sample
Visualisations
4.3
Elements of the Application Sample
The Application Sample ...
• ... enables easy and quick commissioning of a Lenze Automation system by means of examples.
• ... illustrates the possible applications of the L_SMC_AxisBasicControl function block.
4.3.1
The L_SMC_AxisBasicControl block
The L_SMC_AxisBasicControl block ...
• ... enables easy traversing of controllers by using PLCopen functionality.
• ... can be controlled via:
1. The visualisation during manual operation
2. The interfaces of the block (via a PLC program)
Controlling the L_SMC_AxisBasicControl block
The Application Sample shows the control possibilities by means of examples:
1. Example of commissioning via visualisation:
The
AxisBasicControl visualisation can be used to control the
AxisBasicControl program.
2. Example of controlling via the interfaces of the AxisBasicControl FB:
The
ExampleApplications program uses the following blocks which control the interfaces of
the corresponding AxisBasicControl block (X axis, Y axis, Z axis):
• CyclicMove
• Gearing
• Brake-Control
The "programs" are created as function blocks to illustrate by means of an example how
software functions can be reused in the »PLC Designer«.
Folder/symbol
Function
AxisBasicControl
Visualisation for the quick commissioning of the controllers of the Lenze
application case via the L_SMC_AxisBasicControl function.
CyclicMove
Example of application integration in the L_SMC_AxisBasicControl FB.
GearingAxisY
Example of integration of PLCopen functionality for coupling/decoupling:
Second axisfirst axis
BrakeAxisZ
Example of application integration of a holding brake by means of PLCopen
functions.
Diagnostic
Example of diagnostics of the EtherCAT master and the status of the controllers.
"Getting started": information on the use/structure of the Application Sample
