About these instructions
This documentation applies to the Tml vector frequency inverter, and contains important technical
data and describes installation, operation, and commissioning.
Please read the instructions before commissioning.
© 2013 - 2004 Lenze AC Tech Corporation
No part of this documentation may be copied or made available to third parties without the explicit written approval of
Lenze AC Tech Corporation.
All information given in this documentation has been carefully selected and tested for compliance with the hardware and
software described. Nevertheless, discrepancies cannot be ruled out. We do not accept any responsibility nor liability for
damages that may occur. Any necessary corrections will be implemented in subsequent editions.
A B C D E F
Made in USA
Inverter
Tml
Type:
ETML751X2SFA
Id-No: 13xxxxx
N10104
Z519
LISTED
5D81
IND. CONT. EQ.
Input: 1/N/PE (2PE)
230 V
9.2 A
50-60 Hz
Output: 3/PE
0-230 V
4.2 A
0.75 kW
0 - 240 Hz
For detailed information
refer to instruction
Manual TL03
SN: 13xxxxxx012345678
ETML751X2SFA000XX XX XX
1341308801234567
+
- basic I/O
V0006
Scope of delivery Important
• 1 Tml vector inverter (ETML...)
with EPM installed (see Section 4.2)
• 1 Operating Instructions
After receipt of the delivery, check immediately whether the items
delivered match the accompanying papers. Lenze does not accept
any liability for deficiencies claimed subsequently.
Claim
• visible transport damage immediately to the forwarder.
• visible deficiencies/incompleteness immediately to your Lenze
representative.
A Certifications
B Type
C Input Ratings
D Output Ratings E Hardware Version
F Software Version
