Commissioning
Important controller codes
6
l
113 EDK82MV752 DE/EN/FR 7.1
IMPORTANT Possible settings Code
Selection Lenze Name No.
C0517*
v
User menu l After mains switching or in the g
function the code from C0517/1 is
displayed.
l In the Lenze setting the user menu
contains the most important
codes for commissioning the
operating mode "V/f characteristic
control with a linear
characteristic"
l If the password protection is
active, only the codes entered in
C0517 can be freely accessed
l If less than 10 codes are required,
assign the value "0" (zero) to the
memory locations not used. Please
observe that the software
automatically assigns code C0050
to a memory location that is not
used, if it has not been explicitly
assigned to another memory
location.
1 Memory 1 50 C0050 Output frequency (MCTRL1−NOUT)
2 Memory 2 34 C0034 Range of analog setpoint selection
3 Memory 3 7 C0007 Fixed configuration of digital input signals
4 Memory 4 10 C0010 Minimum output frequency
5 Memory 5 11 C0011 Maximum output frequency
6 Memory 6 12 C0012 Acceleration time main setpoint
7 Memory 7 13 C0013 Deceleration time main setpoint
8 Memory 8 15 C0015 V/f rated frequency
9 Memory 9 16 C0016 V
min
boost
10 Memory 10 2 C0002 Parameter set transfer
Possible entries for C0517
xxxx All codes apart from the codes labelled
with "(A)". Syntax:
Codes: C0517/x = cccc
Subcodes: C0517/x = cccc.ss
C0608* Fan monitoring 0 0 Inactive 8200 motec 3 ... 7.5 kW:
Function must be activated during
commissioning (recommended:
C0608 = 1)! Otherwise, the controller
may be destroyed due to overheating.
For all other controllers:
It is essential to set C0608 = 0.
1 TRIP error message
2 Warning
