Commissioning
Vector control
6
l
104 EDK82MV752 DE/EN/FR 7.1
Comment Switch−on sequence
16. Start the motor parameter identification (C0148) Only when the motor is cold!
A Ensure that the controller is inhibited Terminal X3/28 = LOW
B Set C0148 = 1 Press v
C Enable the controller l Terminal X3/28 = HIGH
l The identification starts:
– Segment
c is off
– The motor consumes current and makes a
high−pitched" tone.
– The motor does not rotate!
D If segment c becomes active again after approx. 30 s, inhibit
controller again.
l Terminal X3/28 = LOW
l Identification is completed.
l Calculated and stored:
– V/f rated frequency (C0015)
– Slip compensation (C0021)
– Motor stator inductance (C0092)
l Measured and stored:
– Motor stator resistance (C0084) = Total
resistance of motor cable and motor
17. If necessary, select more parameters Activate e.g. JOG frequencies (C0037, C0038, C0039)
or motor temperature monitoring (C0119)
18. Go to the menu ALL
A Check the fan monitoring setting under code C0608:
– for 8200 motec 0.25...0.37 kW and 0.55...2.2 kW:
C0608 = 0! (default setting)
– for 8200 motec 3...7.5 kW:
C0608 =1 (recommended) or C0608 = 2!
Stop!
Function must be activated during commissioning! Otherwise,
the controller may be destroyed through overheating!
– for all other controllers:
C0608 = 0 ! (default setting)
B Select additional functions via codes, if necessary.
When all settings are complete:
19. Select setpoint E.g. via potentiometer at terminals 7, 8, 9
20. Enable the controller Terminal X3/28 = HIGH
21. The drive is now running. If the drive does not start, additionally press u
